Femur Condylus Buttress Plates (Left and Right Types)
- Compression Fixation:Stability is achieved by pressing the plate tightly against the bone using standard cortical or cancellous screws.
- No Screw Locking Mechanism:Screws do not lock into the plate holes; fixation depends on friction between the plate and bone.
- Good Anatomical Adaptation:The plate can be shaped and contoured during surgery to match the natural anatomy of the bone.
- Flexible Intraoperative Adjustment:Surgeons can adjust plate position and screw placement during the procedure for better fracture reduction.
- Cost-Effective Solution:Compared with locking plates, non-locking plates are generally more economical and suitable for routine trauma cases.
- Suitable for Good Bone Quality:Best used in patients with normal bone density where strong screw purchase can be achieved.
- Wide Clinical Application:Commonly used for upper limb, lower limb, clavicle, fibula, radius, ulna, and other fracture fixation.
More Information About Our Products
- Parameter List
| Product No. | Specification | Length×Width×Thickness(mm) | Material |
|---|---|---|---|
| 166621100050 / 166621100051 | 5 holes L | 119×18.5×5.6 | Pure Titanium |
| 166621200050 / 166621200051 | 5 holes R | 119×18.5×5.6 | Pure Titanium |
| 166621100060 / 166621100061 | 6 holes L | 136×18.5×5.6 | Pure Titanium |
| 166621200060 / 166621200061 | 6 holes R | 136×18.5×5.6 | Pure Titanium |
| 166621100070 / 166621100071 | 7 holes L | 153×18.5×5.6 | Pure Titanium |
| 166621200070 / 166621200071 | 7 holes R | 153×18.5×5.6 | Pure Titanium |
| 166621100080 / 166621100081 | 8 holes L | 170×18.5×5.6 | Pure Titanium |
| 166621200080 / 166621200081 | 8 holes R | 170×18.5×5.6 | Pure Titanium |
| 166621100090 / 166621100091 | 9 holes L | 187×18.5×5.6 | Pure Titanium |
| 166621200090 / 166621200091 | 9 holes R | 187×18.5×5.6 | Pure Titanium |
| 166621100100 / 166621100101 | 10 holes L | 204×18.5×5.6 | Pure Titanium |
| 166621200100 / 166621200101 | 10 holes R | 204×18.5×5.6 | Pure Titanium |
| 166621100110 / 166621100111 | 11 holes L | 221×18.5×5.6 | Pure Titanium |
| 166621200110 / 166621200111 | 11 holes R | 221×18.5×5.6 | Pure Titanium |
Notes:
- The last digit of the product number “0” means non-sterile and “1” means sterile.
- Remark: Used for distal femoral condyle and lateral condyle fractures, select HA4.5 and HB6.5 screws
