Pelvic Locking Plates
- Anatomical design: The plate shape accommodate humerus anatomy, fits close to minimize soft tissue irration;
- Limited-contact design: With advantages as preservation of blood supply to soft tissue and bone ,reunion of the bone fractures,etc;
- Articular multi-holes design: Convenient for fixing selection, with stable fixation;
- Combination locking and compression holes (Combi holes): Using angular stability or compression according to the requirements.
More Information About Our Products
- Parameter List
| Product No. | Specification | Length×Width×Thickness(mm) | Material |
|---|---|---|---|
| 1266210000040 / 1266210000041 | 4holes | 48×10.5×3 | Pure Titanium |
| 1266210000050 / 1266210000051 | 5holes | 59×10.5×3 | Pure Titanium |
| 1266210000060 / 1266210000061 | 6holes | 70×10.5×3 | Pure Titanium |
| 1266210000070 / 1266210000071 | 7holes | 80.5×10.5×3 | Pure Titanium |
| 1266210000080 / 1266210000081 | 8holes | 90×10.5×3 | Pure Titanium |
| 1266210000090 / 1266210000091 | 9holes | 99.5×10.5×3 | Pure Titanium |
| 1266210000100 / 1266210000101 | 10holes | 108×10.5×3 | Pure Titanium |
| 1266210000110 / 1266210000111 | 11holes | 115.5×10.5×3 | Pure Titanium |
| 1266210000120 / 1266210000121 | 12holes | 122×10.5×3 | Pure Titanium |
| 1266210000130 / 1266210000131 | 13holes | 128×10.5×3 | Pure Titanium |
| 1266210000140 / 1266210000141 | 14holes | 132.5×10.5×3 | Pure Titanium |
The last digit of the product number “0” means non-sterile and “1” means sterile.
Remark: For pelvic fracture, choose HC3.5, HC4.0 full thread screws.
